Crystal Eye UTM Gateway Series 30+

Red Piranha

The Series 30+ is a Unified Threat Management (UTM) next-generation firewall (NGFW) hardware/sofrware solution for your medium sized office with up to 1Gb/s WAN links. High performance protection from a variety of evolving threats and risks through a range of integrated services and enterprise class performance in a 1RU from factor with extended storage options.

Specifications

Processor	General Details	Memory Capacity
Intel Generation 10 i-5-10400 (6 cores, 12 threads, 2.9GHz)	Crystal Eye OS Security Solution Hardware Appliance in a 1RU rack mount form factor for WAN links of up to 1Gb/s 1 x HDMI port, x2 USB 2.0, x5 USB 3.1 type A Gen 2 10Gbs x1 USB 3.1 type C Gen 2 10Gbs NVMe M.2 SSD 6Gb/s SATA 3 extended storage subsystem Voltage spike protection 802.3az (Energy Efficient Ethernet) support Certifications: FCC, CE	Ram: 32GB DDR4 2666MHz
Size		Networking Capacity
19” 1U Rack Form Factor 485mm(w) 505mm(d) 44 mm(h)		2 x Intel Gb WAN port 4 x Intel Gb LAN port
Weight		Other Addon Options
12.00
Chipset	Hard Drives and Back Up Storage Capacity
Chipset Z490, Socket 1200	System Drive 1 x 500GB M.2 NVMe
Color Choice	Additional Storage Option
Blue	1 x 2.5in SSD up to 4TB

Processor	General Details	Memory Capacity
Intel Generation 10 i-5-10400 (6 cores, 12 threads, 2.9GHz per CPU)	Dual System Crystal Eye OS Security Solution Hardware Appliance in a rack mount form factor for WAN links of up to 1Gb/s 1 x HDMI port, x2 USB 2.0, x5 USB 3.1 type A Gen 2 10Gbs x1 USB 3.1 type C Gen 2 10Gbs NVMe M.2 SSD 6Gb/s SATA 3 extended storage subsystem Voltage spike protection 802.3az (Energy Efficient Ethernet) support Certifications: FCC, CE	Ram: 64GB DDR4 2666MHz (32GB per CPU)
Size		Networking Capacity
2U Rack Form Factor 482mm(w) 345mm(d) 88.4mm(h)		4 x Intel Gb WAN port (2 per CPU) 8 x Intel Gb LAN port (4 per CPU)
Weight		Other Addon Options
22.00
Chipset	Hard Drives and Back Up Storage Capacity
2 x Chipset Z490, Socket 1200	2 x System Drive 1 x 500GB M.2 NVMe (1 per CPU)
Color Choice	Additional Storage Option
Blue	4 x 2.5in SSD up to 4TB per drive (2 per CPU)

Processor	General Details	Memory Capacity
Intel Generation 10 i-7-10700, (8 cores, 16 threads, 4.9Ghz)	Crystal Eye OS Security Solution Hardware Appliance in a rack mount form factor for WAN links of up to 10Gb/s 1 x HDMI port, x4 USB 2.0, x4 USB 3.2 type A Gen 2 10Gbs X2 USB 3.2 type C NVMe M.2 SSD 6Gb/s SATA 3 storage subsystem Voltage spike protection Certifications: FCC, CE	64GB DDR4 2666MHz
Size		Networking Capacity
2U Rack Form Factor 428mm(w) 593.2mm(d) 88.6mm(h)		1 x Intel Gb WAN port, 1 x 10Gb WAN port 4 x Intel Gb LAN port, 4 Intel 10GB LAN 2 x DUAL SFP 10Gb
Weight		Other Addon Options
24.00
Chipset	Hard Drives and Back Up Storage Capacity
Chipset Z490, Socket 1200	System Drive 1 x 500GB M.2 NVMe
Color Choice	Additional Storage Option
Blue	Up to 6 x 2.5 inch SSD up to 4TB/drive

Processor	General Details	Memory Capacity
Intel i9-10900 10c 20t 5.2Ghz	Crystal Eye OS Security Solution Hardware Appliance in a rack mount form factor for WAN links of up to 10Gb/s 1 x HDMI port, x4 USB 2.0, x4 USB 3.2 type A Gen 2 10Gbs X2 USB 3.2 type C NVMe M.2 SSD 6Gb/s SATA 3 storage subsystem Voltage spike protection Certifications: FCC, CE	Ram: 64GB DDR4 2666MHz
Size		Networking Capacity
2U Rack Form Factor; 428mm(w) 593.2mm(d) 88.6mm(h)		1 x Intel Gb WAN port, 1 x 10Gb WAN port 4 x Intel Gb LAN port, 4 Intel 10GB LAN 2 x DUAL SFP 10Gb
Weight		Other Addon Options
28.00
Chipset	Hard Drives and Back Up Storage Capacity
Chipset Z490, Socket 1200	System Drive 1 x 500GB M.2 NVMe
Color Choice	Additional Storage Option
Blue	Up to 6 x 2.5 inch SSD up to 4TB/drive

Processor	General Details	Memory Capacity
Dual Intel Xeon E5-2697v4 CPU 2.3Ghz	Crystal Eye OS Security Solution Hardware Appliance in a rack mount form factor for WAN links of up to 10Gb/s x 1 VGA, x6 USB 2.0, x4 USB 3.1 type A NVMe M.2 SSD 6Gb/s SATA 3 storage subsystem Certifications: FCC, CE	128GB DDR4 2666MHz
Size		Networking Capacity
2U		2 x Intel XL710-QDA2 Dual Port 40Gb WAN Dual port Total 80gb 2 x Intel XL710-QDA2 Dual Port 40Gb LAN Dual port Total 80gb 1 x Intel X710-T4 quad 10Gb LAN 1 x Dedicated Management port (onboard) 2 x 1 Gb LAN (onboard)
Weight
24.00
Chipset	Hard Drives and Back Up Storage Capacity
Intel C612 Express	System Drive 1 x 500GB M.2 NVMe
Color Choice	Additional Storage Option	Other Addon Options
Blue	Up to 6 x 2.5 inch SSD up to 4TB/drive	Other Addon Options

Warranty and Guarantee

All systems are custom made to your order
All component parts are new and not refurbished
All component parts in assembly are of the highest quality
All systems come with 3 year warranty, 1 year parts and labor then free labor with quoted parts replacement.
